1. High voltage resistance test of electromagnetic winding to the body: the bearing frequency is 50hz The AC test voltage is 2000V, and there is no breakdown after 1s No flashover |
| 2. Insulation resistance of electromagnetic winding to machine body: ≤ 10m Ω in cold state |
3. 25 # transformer oil is used as the insulating oil of electromagnetic winding Oil temperature rise ≤ 65 ℃ |
| 4. The magnetic net is made of stainless high conductivity magnetic material Magnetic property ≥ 15% of the exciting magnetic field strength |
5. The contact parts between the body and raw materials are all imported SUS304 materials |
6. A safe and reliable cooling system is adopted to bring the heat generated by the electromagnetic winding out of the machine to ensure the long-term operation of the machine |
| 7. The automatic alarm device installed in the distribution box provides you with an audible and visual alarm function, so you don't have to worry about affecting the iron removal effect of the slurry due to machine failure |
8.Full automatic iron removal, iron removal, slag removal and cleaning features, no manual operation, convenient and fast cleaning, which saves time and effort |
| 9. In structural design and manufacturing process A series of effective measures have been taken. The service life of this machine is greatly extended |
10. The electrical equipment of this machine can completely guarantee personal safety Reliable Long service life and convenient maintenance |
